STONEDECK
Flame-Finished Natural Slate
12mm (1/2") thick, 1.5mm (1/16") durable
chamfered edge
Base:
Proprietary Engineered Resin , Loctite®
adhered
'Honeycomb' Design supports load-bearing after
trimming
48 'weep' holes prevent freeze/thaw stress
400mm square [+ 2 x 3mm joint], 12mm thick
(15 3/4" square [+ 2 x 1/8" joint], 1/2" thick)
Edge Joint:
(Locking Edge)
2 identical sets of 3mm (1/8") clips and receivers
at 4 sides (16 total contact points per paver)
Automatically aligns and provides even 1/8"
spacing in grid or running bond pattern
Effective Size:
403mm (15 7/8") On Center, 24mm (1") thick
(400mm (15 3/4") Base + 3mm (1/8") shared
joint).
Weight:
Slate: 7 lbs./ft2 • Granite: 8 lbs./ft2 (12-13 lbs.
/paver)
Extremes:
Water Flow Rate:
10+ gallons/minute/joint
Skid Resistance:
0.52 - 0.78 dry 0.47 - 0.74 wet
(μ/coefficient of friction)
Mean Load at first Yield:
1334 lbf
Mean Maximum Load:
1661 lbf
Environment:
-40°C to +126°C (-40°F to +260°F)
Flame-Finished Natural Slate
12mm (1/2") thick, 1.5mm (1/16") durable
chamfered edge
Base:
Proprietary Engineered Resin , Loctite®
adhered
'Honeycomb' Design supports load-bearing after
trimming
48 'weep' holes prevent freeze/thaw stress
400mm square [+ 2 x 3mm joint], 12mm thick
(15 3/4" square [+ 2 x 1/8" joint], 1/2" thick)
Edge Joint:
(Locking Edge)
2 identical sets of 3mm (1/8") clips and receivers
at 4 sides (16 total contact points per paver)
Automatically aligns and provides even 1/8"
spacing in grid or running bond pattern
Effective Size:
403mm (15 7/8") On Center, 24mm (1") thick
(400mm (15 3/4") Base + 3mm (1/8") shared
joint).
Weight:
Slate: 7 lbs./ft2 • Granite: 8 lbs./ft2 (12-13 lbs.
/paver)
Extremes:
Water Flow Rate:
10+ gallons/minute/joint
Skid Resistance:
0.52 - 0.78 dry 0.47 - 0.74 wet
(μ/coefficient of friction)
Mean Load at first Yield:
1334 lbf
Mean Maximum Load:
1661 lbf
Environment:
-40°C to +126°C (-40°F to +260°F)
Custom Search
Our modular and adjustable pedestals
are an easy way to level a surface.
these can be used to create a
framework to support the wood deck
tiles or our unique stone pavers.
are an easy way to level a surface.
these can be used to create a
framework to support the wood deck
tiles or our unique stone pavers.
We represent the AWS pedestal system
and distribute this product nationwide.
This system is very effective.
and distribute this product nationwide.
This system is very effective.
